广东勤乐新材料科技有限公司Guangdong Qinle New Material Technology Co., LTD |
STRETCH FILM (TDS-Technical Data Sheet)
Product Model: TT7650
1. Product Description
PE stretch film (also known as wrap film) has high tensile strength, tear resistance, and good self-adhesive properties, allowing it to wrap objects tightly and prevent them from falling apart during transport. PE stretch film also offers excellent transparency, creating an aesthetically pleasing wrapping effect while protecting them from water, dust, and damage.
2. Basic Product Structure
- Polyethylene Film
- metallocene polyethylene
- tackifying masterbatch
3. Product Characteristics
PE stretch film is made from linear polyethylene, metallocene polyethylene, and a tackifying masterbatch. It is extruded through two or more extruders, shaped through a T-die and chill rollers, stretched, and wound. It features high stretch ratios, puncture resistance, high resilience, and excellent transparency. The film is stretched and wrapped around the packaged item, leveraging its exceptional resilience to secure and protect the item.
4. Product Application Scope
Suitable for pallets and other packaging, widely used in foreign trade export, papermaking, bottle and can making, hardware and electrical appliances, machinery, building materials, agricultural products, food and other industries.Bundling and packaging in electronics, building materials, chemicals, metal products, auto parts, wires and cables, daily necessities, food, papermaking and other industries.
5. Physical Parameters
| Width | 250mm-1500mm | viscosity | ≥2.5N |
| Thickness | 0.012mm-0.04mm | Rupture Force | ≥12N |
| Tensile Strength | ≥7N | Permanent Deformation | ≤55% |
| Elongation At Break | ≥350% | Elastic Recovery | ≥45% |
| Water Vapor Permeability | ≤18g/m2.24h | Inner Diameter Of Tube Core | 76mm—78mm |
6. Customizable
- 500mm width for machine-made films, 300mm, 350mm, 450mm, and 500mm width for hand-made films,, and thicknesses ranging from 15um to 50um.It can be cut online to various specifications.
- Adhesion options include single-sided and double-sided adhesive. The product line includes two main series: hand-made and machine-made stretch film.
7. Product Usage Instructions
- Before use, please clean the surface of the object to be pasted to remove oil, moisture, dust, and other impurities.
- Since pressure-sensitive adhesives are used, a roller or stamping equipment must be used for full pressing during lamination.
- The above technical data are obtained by the company using industry-recognized and reliable testing methods and do not serve as a product specification guarantee.
- When processing conditions are strict, repeated tests should be conducted, and the product can be used only after full verification.
- The optimal storage conditions for the product are 23 ± 5℃ and 50 ± 10% RH (Relative Humidity), with a shelf life of 6 months.
- Storage under conditions such as direct sunlight, high temperature (above 35℃), high humidity (above 70% RH), and low temperature will not be covered by the 6-month shelf life guarantee.
- If the surface of the object is damp, or if the product is used in a dusty, acidic, or alkaline environment, or when laminated with special materials, repeated verification is required before it can be put into use.
- The above data are for reference only and do not provide any legally binding guarantee.
