PET Coated FILM (TDS-Technical Data Sheet)
Product Model: 30050K4
1. Product Description
PE protective film is made by coating acrylic adhesive on one side of a PE (polyethylene) base material and then rolling it up.
2. Basic Product Structure
- Polyethylene Film
- Polyacrylate (Acrylic Adhesive)
3. Product Characteristics
30050K4 is a surface protection material developed using a synthesis technology that involves coating acrylic adhesive on a raw film produced by high-temperature film blowing of polyethylene particles. It features stable adhesiveness and high cleanliness, making it suitable for surface protection during processing, shipment, and transportation. Additionally, it can effectively prevent products from being contaminated, scratched, damaged, or crushed during the production process and transportation.
4. Product Application Scope
Surface protection of hardened materials such as glass covers, mobile phone lenses, PET (polyethylene terephthalate), PMMA (polymethyl methacrylate), and PC (polycarbonate), as well as appearance protection of injection-molded parts and other products.
5. Physical Parameters
| Item | Unit | Characteristic Value | Test Method |
|---|---|---|---|
| Color | / | Transparent | Visual Inspection |
| Thickness | μm | 46 ± 5 | Thickness Gauge |
| Adhesive Type | / | Acrylic | / |
| Peel Strength | gf/25mm | 300 ± 50 | Peel Strength Tester |
| Temperature Resistance | ℃/1H | 60℃/1H | High-Temperature Oven |
| Elongation at Break | % | ≥ 200% | Tensile Testing Machine |
| Tensile Strength | MPa | / | / |
| Appearance (after specified tests) | / | Good | High-Temperature Oven, Constant Temperature and Humidity Tester |
| Residue, Bubbles, Fogging | / | None (Meets Requirements) | / |
6. Customizable
| Customizable Colors | Customizable Gram Weights | Customizable Thicknesses | Customizable Width Sizes | Customizable Length Sizes |
|---|---|---|---|---|
| Transparent, blue, red, etc. | 1 – 2000 g | 40 μm – 150 μm | 1 – 1500 mm | 100 M – 2000 M |
7. Product Usage Instructions
- Before use, please clean the surface of the object to be pasted to remove oil, moisture, dust, and other impurities.
- Since pressure-sensitive adhesives are used, a roller or stamping equipment must be used for full pressing during lamination.
- The above technical data are obtained by the company using industry-recognized and reliable testing methods and do not serve as a product specification guarantee.
- When processing conditions are strict, repeated tests should be conducted, and the product can be used only after full verification.
- The optimal storage conditions for the product are 23 ± 5℃ and 50 ± 10% RH (Relative Humidity), with a shelf life of 6 months.
- Storage under conditions such as direct sunlight, high temperature (above 35℃), high humidity (above 70% RH), and low temperature will not be covered by the 6-month shelf life guarantee.
- If the surface of the object is damp, or if the product is used in a dusty, acidic, or alkaline environment, or when laminated with special materials, repeated verification is required before it can be put into use.
- The above data are for reference only and do not provide any legally binding guarantee.
