PACKING TAPE (TDS-Technical Data Sheet)
Product Model: PJD500-40Y1
1. Product Description
PJD500-40Y1 is based on polypropylene film (BOPP) and coated with environmentally friendly water-based acrylic glue.
2. Basic Product Structure
- Glue: 20±3um
- Base material: 20±2um
3. Product Application Scope
In the packaging field, it is used for carton sealing and fixing.
4. Physical Parameters
| Item | Unit | Characteristic Value | Test Method |
|---|---|---|---|
| Color | / | Transparent | Visual Inspection |
| Thickness | μm | 40 ± 5 | Thickness Gauge |
| Adhesive Type | / | Acrylic | / |
| 180° Peel Strength (N/25mm) | g (Gram) | ≥ 500 | Testing Instrument |
| Ball Tack (Ball #) | Ball # | ≥ 20 | Testing Instrument |
| Holding Power | H (Hour) | ≥ 24 | High-Temperature Oven |
| Longitudinal Tensile Strength | N (Newton) | ≥ 70 N/25mm | Tensile testing machine |
| Elongation at Break | % | ≥ 100% | Tensile testing machine |
5. Product Usage Instructions
- Before use, please clean the surface of the object to be pasted to remove oil, moisture, dust, and other impurities.
- Since pressure-sensitive adhesives are used, a roller or stamping equipment must be used for full pressing during lamination.
- The above technical data are obtained by the company using industry-recognized and reliable testing methods and do not serve as a product specification guarantee.
- When processing conditions are strict, repeated tests should be conducted, and the product can be used only after full verification.
- The optimal storage conditions for the product are 23 ± 5℃ and 50 ± 10% RH (Relative Humidity), with a shelf life of 6 months.
- Storage under conditions such as direct sunlight, high temperature (above 35℃), high humidity (above 70% RH), and low temperature will not be covered by the 6-month shelf life guarantee.
- If the surface of the object is damp, or if the product is used in a dusty, acidic, or alkaline environment, or when laminated with special materials, repeated verification is required before it can be put into use.
- The above data are for reference only and do not provide any legally binding guarantee.
